213
Certification: D.O.T. FMVSS 106, Class AI Air Brake, SAE J1402, Class AI
Description
Parker’s 213 hose is a transportation hose that has a pressure range of 175-2000 PSI and is reinforced with one fiber braid and one steel braid making it excellent for rugged transportation applications.
Technical Specifications
| Cover Color: | Black with Teal accent |
| Media: | Coolants, Fuels, Lubricants, Petroleum Hydraulic Fluids |
| Specifications Met: | D.O.T. FMVSS 106, Class AI Air Brake, SAE J1402, Class AI |
| Compatible Fitting: | 26 Series, 21 Series, 23 Series |
| Weight: | 0.12 to 1.31 lb/ft, 0.18 to 1.95 kg/m |
| Inside Diameter: | 3/16 to 2-3/8 inch, 5 to 61 mm |
| Maximum Operating Pressure: | up to 14.0 MPa, up to 2000 psi, up to 140 bar |
| Application: | Agriculture Equipment, Forestry, Hydraulics, Transportation |
| Hose Reinforcement Material: | 1 Braid of Fiber and 1 Braid of Steel Wire, 1 Braid of Fiber |
| Vacuum Pressure Rating: | 11 to 28 inch-Hg, 279 to 711 mm-Hg |
| Minimum Bend Radius: | 3/4 to 24 inch, 20 to 610 mm |
| Outside Diameter: | 0.49 to 2.88 inch, 12.5 to 73 mm |
| Size: | -4 to -40 |
| Minimum Operating Temperature: | -50 °F, -45 °C |
| Maximum Operating Temperature: | 302 °F, 150 °C |
| Hose Inner Tube Material: | PKR® Rubber |
Additional information
| Part Number | 213-4, 213-5, 213-6, 213-8, 213-10, 213-12, 213-16, 213-20, 213-24, 213-32 |
|---|
