422
EN 853, Type 1SN, ISO 1436, Type 1SN, SAE J517 and 100R1, Type AT
Description
Parker’s 422 hose is a worldwide hydraulic industry standard hose manufactured to strict international specifications to offer customers consistency of performance combined with improved availability anywhere in the world.
Technical Specifications
| Minimum Operating Temperature: | -40 °C, -40 °F |
| Media: | Lubricants, Petroleum Hydraulic Fluids |
| Specifications Met: | EN 853, Type 1SN, ISO 1436, Type 1SN, SAE J517 and 100R1, Type AT |
| Compatible Fitting: | 43 Series, 42 Series |
| Weight: | 0.24 to 2.24 kg/m, 0.16 to 1.5 lb/ft |
| Inside Diameter: | 1/4 to 2 inch, 6.3 to 51 mm |
| Maximum Operating Pressure: | up to 22.5 MPa, up to 3250 psi, up to 225 bar |
| Application: | Agriculture Equipment, Construction Equipment, Forestry, Hydraulics, Material Handling, Transportation |
| Hose Reinforcement Material: | 1 Braid of Steel Wire |
| Vacuum Pressure Rating: | 18 to 24 inch-Hg, 457 to 610 mm-Hg |
| Minimum Bend Radius: | 4 to 25 inch, 100 to 630 mm |
| Outside Diameter: | 0.53 to 2.54 inch, 13 to 64 mm |
| Size: | -4 to -32 |
| Maximum Operating Temperature: | 212 °F, 100 °C |
| Cover Material: | Synthetic Rubber |
| Hose Inner Tube Material: | Synthetic Rubber |
Additional information
| Part Number | 422-4, 422-5, 422-6, 422-8, 422-12, 422-16, 422-20, 422-24, 422-32 |
|---|
