436
ISO, SAE
Description
Parker’s 436 hose is hydraulic compact High temperature hose and has the flexibility to work in tight routing requirements.
Technical Specifications
| Cover Material: | PKR® Rubber MSHA approved |
| Media: | Lubricants, Petroleum Hydraulic Fluids |
| Specifications Met: | ISO, SAE |
| Compatible Fitting: | 43 Series, 42 Series |
| Maximum Operating Pressure: | up to 275 bar, up to 27.5 MPa, up to 4000 psi |
| Weight: | 0.42 to 1.22 kg/m, 0.28 to 0.82 lb/ft |
| Inside Diameter: | 3/8 to 1 inch, 10 to 25 mm |
| Application: | Agriculture Equipment, Construction Equipment, Forestry, Hydraulics, Industrial, Material Handling, Transportation |
| Hose Reinforcement Material: | 2 Braids of Steel Wire |
| Outside Diameter: | 0.68 to 1.41 inch, 17 to 36 mm |
| Size: | -6 to -16 |
| Minimum Bend Radius: | 2-1/2 to 6 inch, 65 to 150 mm |
| Hose Inner Tube Material: | PKR® Rubber |
| Cover Color: | Blue |
| Minimum Operating Temperature: | -55 °F, -48 °C |
| Maximum Operating Temperature: | 302 °F, 150 °C |
| Hose Cover Type: | Standard Cover |
Additional information
| Part Number | 436-6-BLU-RL, 436-8-BLU-RL, 436-10-BLU-RL, 436-12-BLU-RL, 436-16-BLU-RL |
|---|
