RGR
Certification: N/A
Description
RGR Water Hose Assemblies are designed for low pressure water service in applications to 180°F and 125 psi, Series RGR
Technical Specifications
| Minimum Operating Temperature: | -40 °C, -40 °F |
| Hose Inner Tube Material: | Ethylene Propylene Diene Monomer (EPDM), Green |
| Cover Material: | Ethylene Propylene Diene Monomer (EPDM) |
| Specifications Met: | n/a |
| Maximum Operating Pressure: | 100 to 125 psi, 0.04 to 0.86 MPa, 7 to 8.6 bar |
| Weight: | 5.8 to 21.4 lb/ea, 7.68 to 21.39 lb/ea, 2.6 to 9.7 kg/ea, 3.48 to 9.7 kg/ea |
| Length: | 7.6 to 15.2 m, 25 to 100 ft |
| Fitting Material: | Nickel Plated Brass |
| Application: | Water |
| Inside Diameter: | 12.7 to 15.9 mm, 1/2 to 5/8 inch |
| Outside Diameter: | 20.7 to 24.6 mm, 0.813 to 0.969 inch |
| Minimum Bend Radius: | 4.5 to 6 inch, 114.3 to 152.4 mm |
| Connection 1 Type: | Male GHT |
| Nominal Hose Inside Diameter: | 15 to 17.5 mm |
| Connection 2 Type: | Female GHT – Swivel |
| Hose Reinforcement Material: | n/a |
| Maximum Operating Temperature: | 180 °F, 82 °C |
| Base number: | RGR |
| Cover Color: | Green |
Additional information
| Part Number | RGR1250, RGR5825, RGR5850, RGR5875, RGR58100 |
|---|
