SH2PM
BS 5342.0, IS 10655, Type 2
Description
Thermic steam hose meets IS 10655:1999 type 3 / BS 5342. The EPDM hose is with 16 bar working pressure and up to 205 deg C. The EPDM tube and cover is resistant to the HP steam and hot water applications.
Technical Specifications
| Hose Inner Tube Material: | Ethylene Propylene Diene Monomer (EPDM) |
| Minimum Operating Temperature: | 205 °C |
| Cover Material: | Ethylene Propylene Diene Monomer (EPDM) |
| Maximum Operating Pressure: | 1.6 MPa, 16 bar, 232 psi |
| Maximum Operating Temperature: | 205 °C, 401 °F |
| Minimum Bend Radius: | 7 to 25 inch, 178 to 635 mm |
| Weight: | 0.48 to 1.68 lb/ft, 0.72 to 2.50 kg/m |
| Media: | Steam |
| Specifications Met: | BS 5342.0, IS 10655, Type 2 |
| Inside Diameter: | 1/2 to 2 inch, 12.7 to 50.8 mm |
| Application: | Water |
| Hose Reinforcement Material: | 2 Braids of High Tensile Wire |
| Outside Diameter: | 1.05 to 2.76 inch, 26.7 to 70.0 mm |
| Size: | -8 to -32 |
Additional information
| Part Number | SH2PM-8PM, SH2PM-10PM, SH2PM-12PM, SH2PM-16PM, SH2PM-20PM, SH2PM-24PM, SH2PM-32PM |
|---|
