SWC609/SWC609R

N/A

Category:

Description

Titanflex Corrugated Petroleum Transport Suction Hose is designed for delivery, transfer and transport of oil and refined fuels in applications to 200°F and 250 psi

Technical Specifications

Minimum Operating Temperature: -40 °C, -40 °F
Cover Material: Nitrile
Media: Fuels – Check fuel type with our catalogue chart.
Specifications Met: n/a
Inside Diameter: 1-1/4 to 8 inch, 31.8 to 209.2 mm
Cover Color: Black, Red
Hose Reinforcement Material: Multiple Plies of Textile with Dual Wire Helix
Minimum Bend Radius: 1.3 to 16 inch, 33 to 406 mm
Outside Diameter: 1.69 to 8.80 inch, 42.9 to 223.3 mm
Application: Fuel Transfer
Hose Inner Tube Material: Black, Nitrile
Cover Structure: Corrugated
Maximum Operating Temperature: 180 °F, 82 °C
Nominal Hose Inside Diameter: 32 to 200 mm
Weight: 0.63 to 6.95 lb/ft, 0.94 to 10.36 kg/m
Maximum Operating Pressure: 150 to 250 psi, 10.3 to 17.2 bar, 1.0 to 1.7 MPa
Vacuum Pressure Rating: 29 inch-Hg, 737 mm-Hg

Additional information

Part Number

SWC609-1250, SWC609-1500, SWC609-2000, SWC609-2500, SWC609-3000, SWC609-4000, SWC609-6002, SWC609-8002
SWC609R-1500, SWC609R-2000, SWC609R-2500, SWC609R-3000, SWC609R-4000
