SWC693/SWC693B

N/A

Category:

Description

Wildcatter Oilfield UHMWPE Corrugated Chemical Suction Hose is designed for transfer of many industrial strength acids, chemicals and solvents in applications to 180°F and 250 psi

Technical Specifications

Minimum Operating Temperature: -40 °C, -40 °F
Cover Material: Ethylene Propylene Diene Monomer (EPDM)
Media: Chemicals – Check your fluid compatibility with our catalogue chart.
Specifications Met: n/a
Compatible Fitting: n/a
Inside Diameter: 1 to 4 inch, 25.4 to 101.6 mm
Cover Color: Blue, Green
Maximum Operating Pressure: 14 to 17 bar, 1.4 to 1.7 MPa, 200 to 250 psi
Hose Reinforcement Material: Multiple Plies of Textile with Dual Wire Helix
Outside Diameter: 1.47 to 4.61 inch, 37.3 to 117.0 mm
Application: Chemical Transfer
Hose Inner Tube Material: Ultra High Molecular Weight Polyethylene (UHMWPE) (UHMWPE)
Cover Structure: Corrugated
Maximum Operating Temperature: 180 °F, 82 °C
Nominal Hose Inside Diameter: 25 to 100 mm
Weight: 0.38 to 2.7 lb/ft, 0.57 to 2.16 kg/m
Minimum Bend Radius: 1 to 8 inch, 25 to 203 mm
Vacuum Pressure Rating: 29 inch-Hg, 737 mm-Hg

Additional information

Part Number

SWC693-1000, SWC693-1250, SWC693-1500, SWC693-2000, SWC693-3000, SWC693-4000
SWC693B-1000, SWC693B-1250, SWC693B-1500, SWC693B-2000, SWC693B-3000, SWC693B-4000
