1 Wire Braid Reinforcement Hydraulic Hose, Series 481
| Products | Hose I.D. (size) | Certificates | Hose Cover Type |
|---|---|---|---|
| 481-4 | -4 | Non-Specific | Standard |
| 481-5 | -5 | Non-Specific | Standard |
| 481-6 | -6 | Non-Specific | Standard |
| 481-8 | -8 | Non-Specific | Standard |
| 481-10 | -10 | Non-Specific | Standard |
| 481-12 | -12 | Non-Specific | Standard |
| 481-16 | -16 | Non-Specific | Standard |
| 481-20 | -20 | Non-Specific | Standard |
| 481-24 | -24 | Non-Specific | Standard |
| 481-32 | -32 | Non-Specific | Standard |
| 481-4-MH | -4 | MSHA cert. | Standard |
| 481-5-MH | -5 | MSHA cert. | Standard |
| 481-6-MH | -6 | MSHA cert. | Standard |
| 481-8-MH | -8 | MSHA cert. | Standard |
| 481-10-MH | -10 | MSHA cert. | Standard |
| 481-12-MH | -12 | MSHA cert. | Standard |
| 481-16-MH | -16 | MSHA cert. | Standard |
| 481-20-MH | -20 | MSHA cert. | Standard |
| 481-24-MH | -24 | MSHA cert. | Standard |
| 481-32-MH | -32 | MSHA cert. | Standard |
| 481ST-4 | -4 | Non-Specific | Super Tough Cover |
| 481ST-6 | -6 | Non-Specific | Super Tough Cover |
| 481ST-8 | -8 | Non-Specific | Super Tough Cover |
| 481ST-10 | -10 | Non-Specific | Super Tough Cover |
| 481ST-12 | -12 | Non-Specific | Super Tough Cover |
| 481ST-16 | -16 | Non-Specific | Super Tough Cover |
Description
Parker’s 481 hydraulic hose offers customers consistency of performance combined with continuous availability anywhere in the world. Parker’s 481 hydraulic hose has a pressure range of 230-40 bar and designed to wide fluid compatibility. 481 hose designed to accommodate global customer requirements, is manufactured to strict international quality specifications.
The universal one-wire hose is manufactured to international specifications (ISO 1436-1 TYPE 1SN)
It has 1/2 minimum bend radius for ease of routing.
Inner tube is Synthetic rubber.The Reinforcement is 1 wire braids steel wire.The Cover is Synthetic rubber. (MSHA accepted)Temperature Range is from -40°C to +100°C (-40°F to +212°F).
Markets:
•General purpose market.
•Industrial
•Transportation
•Military
•Construction
•Agriculture
•Grounds & Building Maintenance
•Forestry
•Utility Equipment
•Machine Tool
•Waste & Refuse
•Material Handling
Benefits/Features:
•Half SAE bend radius for ease of installation and low force to flex
•Compact construction provides easier routing
•5000-2000 PSI working pressure in different sizes
•Features a smaller O.D. for tighter routing
Application;
•Petroleum base hydraulic fluids and lubricating oils.
The universal one-wire hose is manufactured to international specifications (ISO 1436-1 TYPE 1SN)
It has 1/2 minimum bend radius for ease of routing.
Inner tube is Synthetic rubber.The Reinforcement is 1 wire braids steel wire.The Cover is Synthetic rubber. (MSHA accepted)Temperature Range is from -40°C to +100°C (-40°F to +212°F).
