| Products | Hose I.D. (size) | Hose Cover Type |
|---|---|---|
| 492-4 | -4 | Standard |
| 492-5 | -5 | Standard |
| 492-6 | -6 | Standard |
| 492-8 | -8 | Standard |
| 492-10 | -10 | Standard |
| 492-12 | -12 | Standard |
| 492-16 | -16 | Standard |
| 492-20-WR | -20 | Standard |
| 492ST-6 | -6 | Super Tough |
| 492ST-8 | -8 | Super Tough |
| 492ST-10 | -10 | Super Tough |
| 492ST-12 | -12 | Super Tough |
| 492ST-4 | -4 | Super Tough |
| 492ST-5 | -5 | Super Tough |
| 492ST-16 | -16 | Super Tough |
| 492ST-20 | -20 | Super Tough |
| 492TC-4 | -4 | Tough Cover |
| 492TC-5 | -5 | Tough Cover |
| 492TC-6 | -6 | Tough Cover |
| 492TC-8 | -8 | Tough Cover |
| 492TC-10 | -10 | Tough Cover |
| 492TC-12 | -12 | Tough Cover |
| 492TC-16 | -16 | Tough Cover |
| 492TC-20 | -20 | Tough Cover |
| Weight: | 0.12 to 0.62 lb/ft, 0.18 to 0.93 kg/m |
| Industry: | General Industrial, Off-road Machinery |
| Hose Inner Tube Material: | Nitrile Butadiene Rubber (NBR) |
| Brand: | Parker |
| Minimum Operating Temperature: | -40 °F, -40 °C |
| Maximum Operating Pressure: | 1085 to 4060 psi, 110 to 280 bar, 11.0 to 28.0 MPa |
| Product Type: | Hydraulic Hose |
| Technology: | Fluid & Gas Handling |
| Cover Material: | Synthetic Rubber, Synthetic Rubber High Abrasion Resistant, MSHA approved |
| Design Factor: | 4:1 |
| Division: | Polymer Hose Division Europe |
| Product Style: | Elite No-Skive Compact, Elite No-Skive Compact Tough Cover, Elite No-Skive Super Tough Compact |
| Materials of Construction: | Rubber |
| Minimum Bend Radius: | 2.953 to 13.189 inch, 75 to 335 mm |
| Specifications Met: | EN 857, Type 1SC, ISO 11237, Type 1SC |
| Compatible Fitting: | 46 Series |
| Inside Diameter: | 1/4 to 1-1/4 inch, 6.4 to 31.8 mm |
| Maximum Operating Temperature: | 100 °C (Water 85°C / Air 70°C), 212 °F (Water 185°F / Air 158°F) |
| Application: | Medium Pressure Hydraulics (all markets) |
| Hose Reinforcement Material: | 1 Braid of High Tensile Steel Wire |
| Outside Diameter: | 0.453 to 1.575 inch, 11.5 to 40 mm |
| Media: | Air (General Industrial Air), Coolants (Glycol, Coolants (Glycol), Fuels – Check fuel type with our catalogue chart., Petroleum Hydraulic Fluids |
