HSC
AS/NZS 2070.0, CE 1935/2004
Description
Clearspring Clear/Steel Wired Reinforced Suction Hose is suitable for applications requiring continuous bending and flexing,or where a clear, heavy duty hose is needed. Ideal for food and beverage contact.
Technical Specifications
| Hose Reinforcement Material: | Steel Wire |
| Hose Inner Tube Material: | PVC |
| Nominal Hose Inside Diameter: | 6 to 100 mm |
| Maximum Operating Temperature: | 60 °C, 140 °F |
| Minimum Operating Temperature: | -10 °C, 14 °F |
| Cover Material: | PVC |
| Vacuum Pressure Rating: | 625 to 515 mm-Hg, 20.2 to 27.5 inch-Hg, 699 to 515 mm-Hg |
| Cover Color: | Transparent |
| Media: | Industrial Fluids |
| Specifications Met: | AS/NZS 2070.0, CE 1935/2004 |
| Weight: | 0.1 to 3.35 kg/m |
| Inside Diameter: | 1/4 to 4 inch, 6 to 102 mm |
| Maximum Operating Pressure: | 0.23 to 0.68 bar, 0.23 to 0.68 MPa, 34 to 100 psi |
| Application: | Food & Beverage Processing |
| Design Factor: | 2:1 |
| Minimum Bend Radius: | 0.51 to 8.46 inch, 23 to 215 mm, 13 to 215 mm |
| Outside Diameter: | 11.4 to 116 mm |
| Size: | -4 to -64 |
Additional information
| Part Number | HSC-012-020, HSC-012-030, HSC-012-060, HSC-016-020, HSC-016-030, HSC-020-020, HSC-020-060, HSC-025-020, HSC-025-030, HSC-032-030, HSC-038-030, HSC-050-020 |
|---|
