7301
N/A
Description
Wildcatter Oilfield Hot Oiler Hose is designed for high pressure transfer of hot oil and petroleum products in applications to 275°F and 2250 psi, Series 7301
Technical Specifications
| Minimum Operating Temperature: | -40 °C, -40 °F |
| Cover Material: | Chloroprene Rubber (CR) |
| Maximum Operating Temperature: | 135 °C, 275 °F |
| Application: | Oilfield |
| Weight: | 0.22 kg/m, 1.6 lb/ft, 1.59 lb, 0.72 kg |
| Inside Diameter: | 38.1 mm, 1-1/2 inch |
| Outside Diameter: | 50.8 mm, 2 inch |
| Maximum Operating Pressure: | 15.5 MPa, 2250 psi, 155.1 bar |
| Specifications Met: | n/a |
| Nominal Hose Inside Diameter: | 40 mm |
| Media: | Wet Abrasive Powders |
| Size: | -24 |
| Hose Reinforcement Material: | 2 Braids of Wire |
| Package Type: | Coil |
| Hose Inner Tube Material: | Black, Chloroprene |
| Cover Color: | Black |
| Cover Structure: | Wrapped |
| Minimum Bend Radius: | 13 inch, 330.2 mm |
Additional information
| Part Number | 7301-1502150 |
|---|
