7322/7323

N/A

Category:

Description

Super-Flex GS Large Diameter General Service Air & Water Hose is designed for transfer of air, mild chemicals and water in applications to 212°F and 200 psi

Technical Specifications

Minimum Operating Temperature: -40 °C, -40 °F
Hose Inner Tube Material: Ethylene Propylene Diene Monomer (EPDM) (ARPM Class C Oil Resistance), Black (ARPM Class C Oil Resistance)
Cover Color: Black, Red
Media: Air, Mild Chemicals – Check your fluid compatibility with our catalogue chart., Water
Specifications Met: n/a
Inside Diameter: 1-1/4 to 2 inch, 31.8 to 50.8 mm
Application: Air, Multipurpose
Hose Reinforcement Material: Mutiple Plies of Textile
Minimum Bend Radius: 7.5 to 12 inch, 190.5 to 304.8 mm
Outside Diameter: 1.74 to 2.57 inch, 44.2 to 65.2 mm
Size: -20 to -32
Cover Material: Ethylene Propylene Diene Monomer (EPDM)
Maximum Operating Temperature: 212 °F, 100 °C
Nominal Hose Inside Diameter: 32 to 50 mm
Weight: 0.71 to 1.23 lb/ft, 1.06 to 1.83 kg/m
Maximum Operating Pressure: 200 psi, 13.8 bar, 1.4 MPa

Additional information

Part Number

7322-125200, 7322-150200, 7322-200200
7323-125200, 7323-150200, 7323-200200
