HPW
Other
Description
Pesticide/Weedcide Black covered heavy duty, high pressure spray hose suitable for most agricultural spray or domestic pesticide spray applications.
Technical Specifications
| Hose Inner Tube Material: | PVC |
| Maximum Operating Pressure: | 3.4 MPa, 34 bar, 495 psi |
| Maximum Operating Temperature: | 60 °C, 140 °F |
| Minimum Operating Temperature: | -10 °C, 14 °F |
| Cover Material: | PVC |
| Minimum Bend Radius: | 85 to 140 mm |
| Media: | Chemicals – Check your fluid compatibility with our catalogue chart. |
| Specifications Met: | Other |
| Weight: | 0.19 to 0.39 kg/m |
| Inside Diameter: | 3/8 to 3/4 inch, 10 to 20 mm |
| Compatible Fitting: | Other |
| Application: | Horticultural Equipment, Pest Spray |
| Hose Reinforcement Material: | Fiber |
| Nominal Hose Inside Diameter: | DN10 to 20 |
| Outside Diameter: | 17 to 28 mm |
| Size: | -6 to -12 |
Additional information
| Part Number | HPW-010-200, HPW-012-020, HPW-012-200, HPW-020-020, HPW-020-100 |
|---|
